Lysora LR1500XS High-Performance Cloud Managed Router with 4 x 2.5GbE Ports, Dual 10G SFP+ and 4 Gbps Throughput

The Lysora LR1500XS is a high-performance, cloud-managed multi-Gigabit router designed for commercial surveillance networks, offices, hotels, campuses, and multi-site businesses. Featuring eight RJ45 Ethernet ports, including four 2.5GbE ports, plus two 10GbE SFP+ interfaces, the LR1500XS provides the high-speed connectivity and flexible WAN configuration needed for demanding networking applications.

Powered by a quad-core 1.8 GHz processor with 4 GB RAM, the LR1500XS delivers up to 4 Gbps routing throughput and supports up to 300,000 concurrent sessions, with a recommended capacity of 1,500 concurrent clients. Advanced multi-WAN load balancing, SD-WAN, VPN connectivity, and dynamic routing help businesses maintain secure, reliable connections across multiple locations.

With centralized Lysora Cloud management, installers can remotely configure, monitor, and troubleshoot customer networks without unnecessary on-site visits. Built-in wireless access point management, user authentication, and traffic monitoring make the LR1500XS an excellent choice for professional integrators looking to deploy scalable networking solutions without complicated management infrastructure.

Key Features

High-performance cloud-managed router with 10 total network interfaces
4 x 10/100/1000/2500 Mbps multi-Gigabit RJ45 ports
4 x 10/100/1000 Mbps Gigabit RJ45 ports
2 x 10GbE SFP+ optical interfaces
Flexible LAN/WAN configuration supporting up to 9 WAN connections
Maximum routing throughput of 4,000 Mbps (4 Gbps)
Recommended for up to 1,500 concurrent clients
Supports up to 300,000 concurrent sessions
Quad-core 1.8 GHz processor with 4 GB RAM and 8 GB eMMC storage
Multi-WAN load balancing and policy-based routing
Site-to-site VPN with IPsec and WireGuard
Client-to-site VPN with OpenVPN, L2TP, PPTP, and WireGuard
SD-WAN support with up to 1,200 Mbps performance
Advanced routing including BGP, OSPF, RIP, and IPv4/IPv6 static routes
VLAN support for network segmentation
Built-in wireless access point controller supporting up to 1,000 APs
Captive portal, voucher, SMS, and account-based authentication options
User behavior management, application control, and traffic auditing
Centralized remote management through Lysora Cloud and mobile app
Local web management, SNMP, Syslog, and remote fault diagnosis
Internal SATA 3.0 drive interface for supported local storage functions
Fanless metal enclosure with rack-mount brackets included
Maximum power consumption of just 18W
NDAA compliant; FCC, IC, and cTUVus certified
3-year manufacturer warranty

Technical Specifications

General

Model	LR1500XS
Product Type	High-Performance Cloud Managed Multi-Gigabit Router
Dimensions	440 x 210 x 43.6 mm (17.32 x 8.27 x 1.72 in.)
Net Weight	3 kg (6.61 lbs.)
Packaged Weight	3.82 kg (8.42 lbs.)
Enclosure	Metal
Mounting	Desktop or rack mounting with included brackets
Cooling	Fanless, natural cooling
Warranty	3 Years

Ethernet Ports & Connectivity

Total Network Interfaces	10
Total RJ45 Ports	8
2.5GbE RJ45 Ports	4 x 10/100/1000/2500BASE-T
Gigabit RJ45 Ports	4 x 10/100/1000BASE-T
10GbE SFP+ Ports	2
Fixed WAN Ports	1 x 2.5GbE
Fixed LAN Ports	1 x Gigabit Ethernet
Configurable LAN/WAN Interfaces	8
Maximum WAN Interfaces	9
Maximum LAN Interfaces	9
PoE Output	Not supported
USB Ports	None

Hardware & Performance

Processor	Quad-core, 1.8 GHz per core
RAM	4 GB
Flash Memory	128 MB
eMMC Storage	8 GB
Internal Drive Interface	1 x SATA 3.0 HDD interface
Maximum Routing Throughput	4,000 Mbps
Recommended Concurrent Clients	1,500
Maximum Concurrent Sessions	300,000
Maximum Managed Devices	128
AP Management (Routing Mode)	Up to 1,000 APs
AP Management (AC Mode)	Up to 1,000 APs
System Indicators	System status, 10 network port indicators, HDD indicator
Reset Button	1

Power

Power Method	Internal AC power supply
AC Input	100–240V AC, 50/60Hz
Rated Input Current	1.5A
Maximum Power Consumption	18W
PoE Power Budget	Not applicable; no PoE output

Routing & Network Features

Operating Modes	Routing Mode, AC Mode
Internet Access Methods	PPPoE, DHCP, Static IP
Multi-WAN Load Balancing	Supported
Maximum WAN Interfaces	9
VLAN Support	Supported
Maximum LAN VLANs	128
IPv4 Static Routing	Supported, up to 500 routes
IPv6 Static Routing	Supported, up to 500 routes
Policy-Based Routing	IPv4 and IPv6
IPv4 Policy Routing Entries	30
IPv6 Policy Routing Entries	30
URL-Based Routing	Supported
RIP	Supported, up to 1,000 routes
OSPF	Supported
OSPFv2 Instances	Up to 16
BGP	Supported, up to 10,000 routes
IPv4 / IPv6	Supported
NAT	Supported
Port Mapping Entries	512
DHCP / DNS / DDNS	Supported
UPnP / IPTV	Supported

VPN & SD-WAN Performance

Site-to-Site VPN	IPsec, WireGuard
Client-to-Site VPN	L2TP, L2TP over IPsec, OpenVPN, PPTP, WireGuard
L2TP VPN Throughput	1,150 Mbps
PPTP VPN Throughput	1,450 Mbps
OpenVPN Throughput	300 Mbps
IPsec VPN Throughput	730 Mbps
IPv6 IPsec VPN Throughput	900 Mbps
WireGuard VPN Throughput	1,200 Mbps
L2TP over IPsec Throughput	750 Mbps
SD-WAN	Supported
SD-WAN Performance	1,200 Mbps

Security & Authentication

Access Control Lists (ACL)	Supported
IP-MAC Binding	Supported
MAC Address Filtering	Supported
Security Zones	Supported
Local Attack Defense	Supported
Connection Limiting	Supported
Network Sharing Prevention	Supported
802.1X Authentication	Supported
PPPoE Authentication	Supported
Captive Portal Authentication	Supported
Portal Authentication Options	One-click, SMS, voucher, account, and QR code
Third-Party Portal Support	WISPr, Wi-FiDog
Cloud MAC Authentication Bypass	Supported
RADIUS-Based MAC Authentication	Supported

Gateway & Traffic Management

User Behavior Management	Supported
Application Control	Supported
Flow Control	Supported
Traffic Auditing	Supported
Audit Logging	Supported
Local Traffic Audit Log Storage	Supported
ARP Table Capacity	4,096 entries
DHCP Snooping	Not supported
VRRP	Not supported

Wireless Access Point Management

Built-In AP Controller	Supported
Maximum APs (Routing Mode)	1,000
Maximum APs (AC Mode)	1,000
Maximum SSIDs	8
Wi-Fi RF Configuration	Supported
AP Mesh Management	Supported
802.11k/v Roaming Management	Supported
AP Load Balancing	Supported
Client Allowlist / Blocklist	Supported
AP Portal Authentication	Supported
Layer 2 Client Isolation	Supported

Management & Monitoring

Cloud Management	Lysora Cloud
Mobile App Management	Supported
Local Web Management	Supported
HTTP / HTTPS Login	Supported
Remote Device Restart	Supported through app
Cloud Firmware Upgrades	Supported
Self-Organizing Network	Supported
Fault Diagnosis	Supported
Syslog	Supported
SNMP	Supported
RLOG	Supported
NTP Client	Supported
SSH / Telnet	Not supported
Stacking	Not supported

Environmental & Reliability

Operating Temperature	0°C to +40°C (32°F to 104°F)
Storage Temperature	-40°C to +70°C (-40°F to 158°F)
Operating Humidity	10% to 90% RH, non-condensing
Service Port Surge Protection	±6 kV common mode
Power Connector Surge Protection	±6 kV common and differential mode
ESD Protection	6 kV contact discharge; 8 kV air discharge
Cooling	Fanless, natural cooling

Compliance & Certifications

NDAA Compliant	Yes
Certifications	FCC, IC, cTUVus
EMC Standard	FCC Part 15B
Safety Standard	UL 62368-1

Package Contents

LR1500XS Router	1
User Manual	1
Warranty Card	1
Rubber Pads	4
Rack-Mount Brackets	2
Mounting Screws	8 x M4 x 8 mm
Power Cord	1
Power Cord Retention Clip	1

Note: The LR1500XS does not provide PoE power output. A separate PoE switch is required for compatible IP cameras and wireless access points. Maximum routing throughput is 4 Gbps; actual performance depends on traffic type, enabled services, VPN protocol, and network configuration. The SATA interface is intended for supported local storage functions and is not a substitute for an NVR. Specifications and software capabilities are subject to manufacturer updates.
