10-Port Cloud Managed Router with 110 W PoE Budget

- Desktop 10-port full gigabit router, providing one WAN port, six LAN ports, and three LAN/WAN ports

- Supporting eight PoE/PoE+ interfaces and maximum 110 W PoE power
- Recommended concurrency of 300, maximum 1.5 Gbps throughput
- Cloud remote management supported

  • SKU: LR300G-P
In Stock & Ready To Ship!
Current Stock:Only left:
Description

Lysora LR300G-P 10-Port Gigabit Cloud Managed Router with 8 PoE+ Ports and 110W PoE Budget

The Lysora LR300G-P is a compact, cloud-managed Gigabit router designed for small and medium-sized commercial networks, IP surveillance systems, offices, retail stores, and multi-site installations. Combining advanced routing capabilities with eight PoE/PoE+ ports, the LR300G-P simplifies network infrastructure by providing both network management and power delivery in one device.

Featuring ten Gigabit Ethernet ports, including one dedicated WAN port, six LAN ports, and three configurable LAN/WAN ports, the LR300G-P supports flexible network configurations and multi-WAN connectivity. With up to 1.5 Gbps throughput, a 110W total PoE power budget, and centralized Lysora Cloud management, it delivers a cost-effective networking solution without recurring cloud management licensing fees.

Key Features

  • 10-port Gigabit cloud-managed router with integrated PoE switching
  • 1 x dedicated Gigabit WAN port, 6 x dedicated LAN ports, and 3 x configurable LAN/WAN ports
  • 8 x IEEE 802.3af/at PoE/PoE+ output ports
  • 110W total PoE power budget for compatible IP cameras, wireless access points, and other powered devices
  • Up to 1.5 Gbps routing throughput
  • Up to 100,000 concurrent sessions
  • Recommended capacity of up to 350 concurrent clients
  • Dual-core 1.35 GHz processor with 512 MB RAM
  • Multi-WAN load balancing and policy-based routing
  • IPsec, WireGuard, OpenVPN, L2TP, and PPTP VPN support
  • Advanced routing features including static routing, OSPF, BGP, and RIP
  • VLAN support for separating surveillance, business, and guest networks
  • Centralized remote management through Lysora Cloud and mobile app
  • Access Point management and self-organizing network capabilities
  • Fanless metal enclosure for quiet desktop operation
  • 3-year manufacturer warranty

Technical Specifications

General

Model LR300G-P
Product Type Cloud Managed Gigabit PoE Router
Dimensions 202 x 108 x 28 mm (7.95 x 4.25 x 1.10 in.)
Net Weight 0.55 kg (1.21 lbs.)
Packaged Weight 1.62 kg (3.57 lbs.)
Enclosure Metal
Mounting Desktop
Cooling Fanless, natural convection
Warranty 3 Years

Ethernet Ports & PoE

Total Ethernet Ports 10 x 10/100/1000BASE-T RJ45
Fixed WAN Ports 1 x Gigabit Ethernet
Fixed LAN Ports 6 x Gigabit Ethernet
Configurable LAN/WAN Ports 3 x Gigabit Ethernet
Maximum WAN Ports 4
Maximum LAN Ports 9
PoE Output Ports 8 x PoE/PoE+ (IEEE 802.3af/at)
Total PoE Budget 110W shared
PoE Power Pins 1-2 (+), 3-6 (-)
SFP / Fiber Ports None
2.5GbE / 10GbE Ports None

Hardware & Performance

Processor Dual-core, 1.35 GHz per core
RAM 512 MB
Flash Memory 256 MB
Maximum Concurrent Sessions 100,000
Recommended Concurrent Clients 350
Maximum Throughput 1.5 Gbps
Status Indicators 1 x System LED, 10 x Ethernet Port LEDs
Reset Button 1

Power

Power Supply External 54V DC power adapter
Rated AC Input 100-240V AC, 50/60Hz
Adapter Output 54V DC, up to 2.4A
Power Consumption (No PoE Load) 9W
Maximum Power Consumption (Full PoE Load) 119W
Total PoE Output Budget 110W
DC Connector 5.5 mm outer diameter, 2.1 mm inner diameter, 10 mm depth

Routing & Networking

Operating Modes Routing Mode and AC Mode
Internet Access Methods PPPoE, DHCP, Static IP
Multi-WAN Load Balancing Supported
Static Routing IPv4 and IPv6
Policy-Based Routing (PBR) IPv4 and IPv6
URL-Based Routing Supported
Dynamic Routing Protocols RIP, OSPF, BGP
VLAN IEEE 802.1Q
Maximum VLANs 64
IPv4 / IPv6 Supported
NAT Supported
DHCP Server Supported
Dynamic DNS (DDNS) Supported
Port Mapping Entries Up to 512
UPnP Supported
IPTV Supported

VPN & Remote Connectivity

Site-to-Site VPN IPsec, WireGuard
Client-to-Site VPN L2TP, L2TP over IPsec, OpenVPN, PPTP, WireGuard
WireGuard VPN Throughput Up to 300 Mbps
IPsec VPN Throughput Up to 170 Mbps
OpenVPN Throughput Up to 100 Mbps
L2TP VPN Throughput Up to 540 Mbps
L2TP over IPsec Throughput Up to 160 Mbps
PPTP VPN Throughput Up to 640 Mbps

Security & Access Control

Access Control Lists (ACL) Supported
IP-MAC Binding Supported
MAC Address Filtering Supported
Security Zones Supported
Local Attack Defense Supported
Connection Limiting Supported
Application Control Supported
User Behavior Management Supported
Traffic Auditing Supported
802.1X Authentication Supported
Captive Portal Authentication Local and cloud-based portal options
Third-Party Portal Authentication WISPr and Wi-FiDog

Wireless AP Management

AP Controller Mode Supported
Maximum Managed APs (Routing Mode) 150
Maximum Managed APs (AC Mode) 500
Self-Organizing Network Supported
Maximum Devices in Self-Organizing Network 128
Maximum SSIDs 8
AP Mesh Management Supported
802.11k/v Roaming Management Supported
AP Load Balancing Supported
AP Client Management Supported

Management & Monitoring

Cloud Management Lysora Cloud
Mobile Management Lysora App
Local Management Web Interface (HTTP/HTTPS)
Remote Firmware Updates Supported
Remote Device Restart Supported
Remote Monitoring Supported
Fault Diagnosis Supported
SNMP Supported
Syslog Supported
SSH / Telnet Not supported
Cloud Management Licensing No recurring cloud management license fees

Environmental & Reliability

Operating Temperature -10°C to +50°C (14°F to 122°F)
Storage Temperature -40°C to +70°C (-40°F to 158°F)
Operating Humidity 0% to 100% RH, non-condensing
Storage Humidity 0% to 100% RH, non-condensing
Ethernet Port Surge Protection ±4 kV common mode
Power Connector Surge Protection ±4 kV common and differential mode
ESD Protection 4 kV contact, 6 kV air
Cooling Method Fanless, natural cooling

Package Contents

LR300G-P Router 1
User Manual 1
Warranty Card 1
Rubber Feet / Pads 4
Power Cord 1

Note: The 110W PoE budget is shared across all eight PoE output ports. Total connected device power requirements must remain within the available budget and individual port limits. Maximum routing throughput, VPN performance, and client capacity are manufacturer-stated values and may vary depending on traffic patterns, enabled features, and network configuration. Specifications are subject to manufacturer updates.
