Description
48-Port 10G L2 Managed POE Switch, 48 Gigabit RJ45 POE/POE+ Ports,4 *1G SFP Slots, 370W PoE Power budget,19-inch Rack-mountable Steel Case
| Technical Specifications | |
|---|---|
| Physical | |
| Dimensions | 440 × 293 × 44 mm (17.32 × 11.54 × 1.73 in.) |
| Weight | 5.86 kg (12.92 lbs) with packaging 4.32 kg (9.52 lbs) without packaging |
| Casing | Metal |
| Mounting | Rack / Desktop |
| Warranty | 3 Years |
| Ports | |
| Total RJ45 Ports | 48 |
| 1GE SFP Ports | 4 |
| 10/100/1000BASE-T Ports | 48 |
| PoE | |
| PoE Ports | 48 × PoE/PoE+ |
| PoE Budget | 370W |
| PoE Pin Assignment | 1–2 (+), 3–6 (-) |
| Hardware | |
| Switching Capacity | 104 Gbps |
| Forwarding Rate | 77.38 Mpps |
| Buffer Size | 4.1 Mbit |
| CPU | MAC Chip, Dual-Core 1GHz Processor |
| Memory | 512MB RAM / 256MB Flash |
| Recommended Camera Capacity | 200W PoE Budget: Up to 200 H.265 Cameras 400W PoE Budget: Up to 100 H.265 Cameras |
| Power | |
| Power Input | 100–240VAC, 50/60Hz Maximum Input: 90–264VAC Maximum Current: 6A |
| Maximum Power Consumption | 46W (No PoE Load) 450W (Full PoE Load) |
| Heat Dissipation | 157.32 BTU/hr (No PoE) 1539 BTU/hr (Full PoE) |
| Environmental | |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Operating Humidity | 10% to 90% RH (Non-condensing) |
| Storage Humidity | 5% to 95% RH (Non-condensing) |
| Cooling | 2 Fixed Fans, Side-to-Rear Airflow |
| Operating Altitude | -500m to 5,000m |
| MTBF | 400,000 Hours |
| ESD Protection | 6kV Contact / 8kV Air |
| Surge Protection | ±6kV Service Port & Power Connector |
| Layer 2 Features | |
| Maximum VLANs | 4094 |
| MAC Address Table | 16,000 Entries |
| Port-Based VLAN | Yes |
| 802.1Q VLAN | Yes |
| Voice VLAN | Yes |
| STP / RSTP / MSTP | Yes |
| LLDP / LLDP-MED | Yes |
| LACP | Yes |
| Static Link Aggregation | Yes |
| Rate Limiting | Ingress / Egress |
| IP Services | |
| ARP | Yes |
| IPv4 / IPv6 Ping | Yes |
| Traceroute | IPv4 & IPv6 |
| DNS / DNSv6 Client | Yes |
| DHCP Server / Client / Relay | Yes |
| Multicast | |
| IGMP Snooping | v1 / v2 / Basic v3 |
| IGMP Filtering | Yes |
| QoS & ACL | |
| Standard / Extended ACL | Yes |
| 802.1p & DSCP Priority | Yes |
| Queue Scheduling | SP, SP+WRR, WRR |
| Congestion Control | Tail Drop |
| Security | |
| 802.1X Authentication | Port & MAC Based |
| Port Isolation | Yes |
| Storm Control | Broadcast / Multicast / Unknown Unicast |
| DHCP Snooping | Yes |
| IP Source Guard | Yes |
| ARP Anti-Spoofing | Yes |
| CPU Protection | Yes |
| Management | |
| Web Management | Yes |
| Cloud Management | Yes |
| Mobile App Management | Yes |
| Self-Organizing Network (SON) | Yes |
| HTTPS Login | Yes |
| Syslog / RLOG | Yes |
| SNMP | v1 / v2c / v3 |
| NTP Client | Yes |
| Camera Detection | Yes |
| PoE Watchdog | Yes |
| Local & Online Firmware Upgrade | Yes |
| Interface Features | |
| Jumbo Frame | 9216 Bytes |
| EEE | Yes |
| Cable Test | Yes |
| Compliance | |
| NDAA Compliant | Yes |
| EMC | FCC Part 15 Subpart B, ICES-003 Issue 7 |
| Safety | UL 62368-1:2019 |
| Certifications | FCC, IC, cTUVus |
| Package Contents | |
| Switch | 1 |
| User Manual | 1 |
| Warranty Card | 1 |
| Rubber Feet | 4 |
| Power Cord Retention Clip | 1 |
| M4 Mounting Screws | 6 |
| Grounding Cable | 1 × 1m |
| Power Cord | 1 × 1.5m |
| Rack Mount Brackets | 2 |
