Wi-Fi 7 BE3600 dual-band ceiling mount access point
Dual-band 2.4 GHz/5 GHz, high throughput with 4 spatial streams
1 x 100/1000/2500BASE-T port
AP and routing mode
Unified networking and management based on Lysora Cloud App; max power consumption < 14 W
802.3at PoE In and 12 V DC power supply

  • SKU: L7LITE
In Stock & Ready To Ship!
Current Stock:Only left:
Description

Lysora L7Lite Wi-Fi 7 BE3600 Dual-Band Indoor Access Point

The Lysora L7Lite is a compact Wi-Fi 7 access point designed for reliable, high-speed wireless connectivity in offices, retail stores, hospitality environments, and commercial buildings. Featuring dual-band BE3600 performance, a 2.5GbE uplink, and centralized cloud management, the L7Lite delivers next-generation networking capabilities in a cost-effective, easy-to-deploy solution.

Key Features

  • Wi-Fi 7 (802.11be) BE3600 dual-band performance
  • Up to 3,570 Mbps combined theoretical wireless data rate
  • 4 spatial streams with 2x2 MU-MIMO per band
  • 1 x 2.5GbE RJ45 port for high-speed wired connectivity
  • Up to 140 m² (1,507 sq. ft.) coverage in ideal conditions
  • Up to 110 recommended associated clients under specified conditions
  • Multi-Link Operation (MLO) and 4K-QAM support
  • 160 MHz channel bandwidth on 5 GHz
  • PoE or 12V DC power input
  • Maximum power consumption of 14W
  • License-free centralized management through Lysora Cloud
  • Wireless meshing and Layer 2/Layer 3 roaming
  • Ceiling or wall mounting hardware included
  • NDAA compliant

Technical Specifications

General

Model L7Lite
Product Type Indoor Wi-Fi 7 Access Point
Wi-Fi Standard IEEE 802.11 a/b/g/n/ac/ax/be
Dimensions Ø195 x 41 mm (7.68 x 1.61 in.)
Weight ≤ 0.6 kg (1.32 lbs.)
Coverage Area 140 m² (1,507 sq. ft.)
Maximum Associated Clients 511 combined (manufacturer-stated limit)
Recommended Clients Up to 110 (Wi-Fi 6, 160 MHz); 100 (80 MHz); 80 (Wi-Fi 5)
Mounting Ceiling or wall (mounts included)

Wireless Performance

Frequency Bands 2.4 GHz and 5 GHz
Spatial Streams 4
MIMO 2x2 MU-MIMO per band
2.4 GHz Data Rate Up to 688 Mbps
5 GHz Data Rate Up to 2882 Mbps
Combined Data Rate Up to 3570 Mbps
2.4 GHz Channel Width 20/40 MHz
5 GHz Channel Width 20/40/80/160 MHz
2.4 GHz Antenna Gain 3.23 dBi
5 GHz Antenna Gain 4.44 dBi
Multi-Link Operation (MLO) Supported
4096-QAM (4K-QAM) Supported
RF Beamforming Supported
Band Steering Supported
Wireless Meshing Supported

Interfaces & Power

Network Interface 1 x 2.5GbE RJ45 (10/100/1000/2500 Mbps)
Power Input 802.3at PoE or 12V DC, 1.5A
Power Consumption ≤ 14W
Status Indicator 1 x System Status LED
Reset Button 1
DC Power Adapter Not included

Software & Networking

Operating Modes Access Point and Router
Maximum SSIDs 8
VLAN 802.1Q supported
Wireless Roaming 802.11k/v/r
Layer 2 Roaming Supported
Layer 3 Roaming Supported
Client Isolation Supported
Wi-Fi Scheduling Supported
WMM Supported
Captive Portal Supported
Bandwidth Limiting Supported
Routing Features NAT, DHCP Server, Static IP, PPPoE
Network Diagnostics Ping and Traceroute
Mesh Management Supported

Security

Wireless Security WPA, WPA2, WPA3-SAE, OWE
Authentication PSK and 802.1X
Mixed Security Mode WPA2-PSK/WPA3-SAE
Client Device Isolation Supported

Management

Cloud Management Lysora Cloud
Mobile Management Lysora App
Local Management Web Interface
SNMP Supported
AI Optimization Supported
Self-Organizing Network Up to 300 APs
Unified Network Management Supported

Environmental & Compliance

Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% RH, non-condensing
IP Rating IP41
Surge Protection ±2 kV
NDAA Compliant Yes (manufacturer stated)
Certifications Listed FCC, ISED, cTUVus, TEC, WPC, TELEC, VCCI

Package Contents

Access Point 1 x L7Lite
Mounting Bracket 1
Mounting Screws 4
Expansion Anchors 4
Security Lock Key 1
Alignment Sticker 1
User Manual 1
Warranty Card 1

Note: Wireless throughput represents theoretical maximum data rates. Actual performance, coverage, and client capacity vary depending on installation conditions, interference, connected devices, and network configuration. Wi-Fi 7 features require compatible client devices. Specifications are subject to manufacturer updates.
