Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800

Write a Review
Ask Questions
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800
Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800

Lysora L6Lite Ceiling Mount Access Point Wi-Fi 6 AX1800

Login to view pricing

Wi-Fi 6 AX1800 dual-band ceiling mount access point with built-in antennas
1 x 1GE LAN port
dual-band 2.4 GHz/5 GHz
in compliance with 802.11ax and 802.11ac (Wave 1/Wave 2)
wireless data rate of up to 1774 Mbps
AP mode and routing mode
Layer 3 roaming
unified networking and management based on Lysora Cloud App
PoE In and local power supply (PoE injector and DC adapter purchased separately)

  • SKU: L6Lite
In Stock & Ready To Ship!
Current Stock:Only left:
Description

Lysora L6Lite Wi-Fi 6 AX1800 Dual-Band Indoor Access Point

The Lysora L6Lite is a compact, cost-effective Wi-Fi 6 access point designed to deliver reliable wireless connectivity in offices, retail stores, hospitality environments, and other indoor spaces. Featuring dual-band AX1800 performance, support for up to 256 connected clients, and centralized cloud management, the L6Lite offers a practical networking solution for professional installations.

Key Features

  • Wi-Fi 6 (802.11ax) AX1800 dual-band wireless performance
  • Up to 1,774 Mbps combined theoretical wireless data rate
  • 4 spatial streams with 2x2 MU-MIMO per band
  • Supports up to 256 connected clients (100 recommended with Wi-Fi 6)
  • Up to 125 m² (1,345 sq. ft.) coverage in ideal conditions
  • 1 x Gigabit Ethernet RJ45 port
  • PoE or 12V DC power input
  • Maximum power consumption of just 12.95W
  • Cloud management through Lysora Cloud and mobile app
  • Wireless meshing and Layer 2/Layer 3 roaming
  • Ceiling or wall mounting hardware included
  • NDAA compliant

Technical Specifications

General

Model L6Lite
Product Type Indoor Wi-Fi 6 Access Point
Wi-Fi Standard IEEE 802.11 a/b/g/n/ac/ax
Dimensions Ø175 x 39 mm (6.89 x 1.54 in.)
Weight ≤ 0.4 kg (0.88 lbs.)
Coverage Area 125 m² (1,345 sq. ft.)
Maximum Clients 256 combined
Recommended Clients 100 with Wi-Fi 6; 80 with Wi-Fi 5
Mounting Ceiling or wall (mounts included)

Wireless Performance

Frequency Bands 2.4 GHz and 5 GHz
Spatial Streams 4
MIMO 2x2 MU-MIMO per band
2.4 GHz Data Rate Up to 573 Mbps
5 GHz Data Rate Up to 1201 Mbps
Combined Data Rate Up to 1774 Mbps
2.4 GHz Channel Width 20/40 MHz
5 GHz Channel Width 20/40/80 MHz
2.4 GHz Antenna Gain 3.13 dBi
5 GHz Antenna Gain 4.64 dBi
RF Beamforming Supported
Band Steering Supported
Wireless Meshing Supported

Interfaces & Power

Network Interface 1 x 10/100/1000BASE-T RJ45
Power Input PoE or 12V DC, 1.5A
Power Consumption ≤ 12.95W
Status Indicator 1 x System Status LED
Reset Button 1
DC Power Adapter Not included

Software & Networking

Operating Modes Access Point and Router
Maximum SSIDs 8
VLAN 802.1Q supported
Wireless Roaming 802.11k/v/r
Layer 2 Roaming Supported
Layer 3 Roaming Supported
Client Isolation Supported
Wi-Fi Scheduling Supported
WMM Supported
Captive Portal Supported
Bandwidth Limiting Supported
Routing Features NAT, DHCP Server, Static IP, PPPoE
Network Diagnostics Ping and Traceroute
Mesh Management Supported

Security

Wireless Security WPA, WPA2, WPA3-SAE, OWE
Authentication PSK and 802.1X
Mixed Security Mode WPA2-PSK/WPA3-SAE
Client Device Isolation Supported

Management

Cloud Management Lysora Cloud
Mobile Management Lysora App
Local Management Web Interface
SNMP Supported
AI Optimization Supported
Self-Organizing Network Up to 300 APs
Unified Network Management Supported

Environmental & Compliance

Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% RH, non-condensing
IP Rating IP41
Surge Protection ±2 kV
NDAA Compliant Yes
Certifications Listed FCC, ISED, cTUVus, TEC, WPC, TELEC, VCCI

Package Contents

Access Point 1 x L6Lite
Mounting Bracket 1
Mounting Screws 4
Expansion Anchors 4
Security Lock Key 1
Alignment Sticker 1
User Manual 1
Warranty Card 1

Note: Wireless throughput represents theoretical maximum data rates. Actual performance, coverage, and client capacity depend on installation conditions, interference, and network configuration. Specifications are subject to manufacturer updates.
